IMMULITE 2000 XPi Immunoassay System


immulite_2000_xpi_flyer.pdf


The IMMULITE® 2000 XPi System is an easy to use, continuous random-access immunoassay analyser with one of the largest automated immunoassay menus available.

With a maximum throughput of 200 tests per hour, medium to high-volume laboratories can incorporate speciality and allergy testing into routine workloads to improve productivity and efficiency.

Features

  • Customised automated startup for daily routine maintenance and quality control scheduling
  • Reagent onboard stability of 90 days, minimises waste
  • Maximum throughput of 200 tests per hour
  • No pause sample loading to enhance turnaround time
  • Tube-top sample cups for micro-sample handling
  • Home screens with at-a-glance status on a 19" touch screen monitor
  • Options available for direct water feed and bulk solid waste chute
  • Siemens Automation solution available through VersaCell® Systems

Specifications

Overview

System Description

Random access immunoassay system
Throughput

Up to 200 tests per hour in batch or random access mode
Time to First Result

35 minutes
Assays Onboard

24


Assays

Assay Onboard Stability

90 days
Assay Technology

Enzyme amplified Chemiluminescence
Disease-state Assay Groups

Allergy, Anaemia, Autoimmune, Bone, Cardiac, Diabetes, Growth, Hepatitis, Inflammation, Metabolic, Oncology, Reproductive, Special ID, Therapeutic Drug Monitoring, Thyroid, ToRCH, Veterinary
Assay Calibration
System indicates when calibration is required
Specific sample type available for calibration verification


Samples and Sample Handling

Sample Tubes
12-16mm diameter, 75-100mm height, 10 x 50 microtubes with tube top racks
Sample Carriers
90 samples, continuous loading in 15 position sample racks
Walk-away Time
Up to 5 hours
Sample Types
Serum, plasma, urine - assay dependent
Sample Integrity Control
Pressure-transducer technology with clot detection, clot flagging and short sample detection
Automatic Processing
Reflex and re-run testing and dilutions


Barcodes

Formats Supported

Code 39, Codabar, UPC, Code 128, 1-2 of 5 (interleaved)


Reagents and Reagent Handling

Reagent Cooling

2-8°C
Reagent Preparation

None required
Reagent Onboard Stability

90 days
Reagent Integrity Control

Barcodes allow system to identify lot number, determine when calibrator adjustment needed and the remaining number of tests in the reagent wedge


Cuvettes

Type
Individual reaction tubes
Onboard Capacity
1300


Maintenance

Daily
Automated daily maintenance cycle completed according to time programmed by the laboratory
Weekly
20 minutes
Monthly
45 minutes


User Interface

Operating System
Microsoft® Windows® 7
Monitor
19" touch sensitive screen


Quality Control

Package
Includes graphs and QC rules options for controls


Environmental

Operating Temperature
18-32°C and 40-80% humidity
Electrical
200-240 V, 6 AMP, 50/60Hz, 6 Amp


Weight & Dimensions

Weight
363kg
Height
165cm
Width
236cm
Depth
114cm


If you would like more information please call +44 (0) 1204 695045 or email sales@quantumvetdiagnostics.com
