i-Smart 30 VET Electrolyte Analyser


i_smart_30_vet_flyer.pdf

i_smart_30_how_to_run_a_sample.pdf

Resources


The i-Smart® 30 VET Electrolyte Analyser is a state of the art electrolyte analyser with a modern design, large LCD touch screen and a built-in printer.

Features

  • No user maintenance
  • Autocalibration
  • Cartridge contains electrodes and all consumables
  • Vet specific software
  • Fast, accurate electrolyte analysis
  • Tests electrolytes Na+, K+, Cl- and iCa++
  • Small, bench top unit
  • 60μl sample volume
  • Results in 35 seconds
  • Specific animal species reference ranges
  • 300,000 test data storage
  • Large LCD touch screen
  • Battery or mains powered


The i-Smart 30 performs accurate electrolyte analysis quickly and displays results within 35 seconds. It has an “all-in-one” cartridge containing all consumables required for the tests including reagents, electrodes and sample probe.




Species Specific Electrolyte Analysis

Species specific reference ranges enable Sodium, Potassium and Chloride results to be compared to normal levels. The comparison feature compares results taken over a period of time for the same animal, to assess if health is improving or deteriorating.

Measured Electrolytes

  • Sodium (Na+): 20 - 250 mmol/L
  • Potassium (K+): 0.5 - 20 mmol/L
  • Chloride (Cl-): 20 - 250 mmol/L
  • Ionised Calcium (iCa++): 0.25 ~ 5.00 mmol/L

The i-Smart 30 VET Electrolyte Analyser has a memory capable of storing data for 300,000 tests. It is both autocalibrated and compact, meaning it is ideal for immediate in-practice electrolyte analysis.

As a portable electrolyte analyser, it can run off its own battery or be powered from the mains. It requires no maintenance and can provide accurate results quickly.

Kit Contents

  • i-Smart 30 VET Electrolyte Analyser
  • An i-Smart stand
  • Barcode scanner
  • Power pack
  • 6 x paper rolls
  • Operator manual

i-Smart 30 VET Cartridges are supplied separately to the i-Smart 30 VET Analyser. Each cartridge contains the following components:

  • 3 x Electrodes
  • 2 x Calibration Fluids
  • Reference Solution
  • Sampler & Tubing
  • Waste Bag

Analyser Specifications

Measuring Range
Na+ : 20 ~ 250 mmol/L
K+ : 0.5 ~ 20 mmol/L
Cl- : 20 ~ 250 mmol/L
iCa++: 0.25 ~ 5.00 mmol/L
Sample Type
Whole blood / plasma
Sample Volume
60µl
Sample Analysis Time
35 seconds
Measuring Principle
Electrochemistry (Direct ISE)
Computer
1 GHz Process
1 Gbyte RAM
4 Gbyte Flash Memory
Operating System
Microsoft Windows® XP Embedded
Display
7 inch TFT LCD Touch Screen
Printer
Thermal, 2 inch width paper
Dimension / Weight
29.2 x 25.6 x 17.7 cm / 5.5 Kg
Voltage
100 ~ 240 VAC
47 ~ 63 Hz
Frequency
47 ~ 63 Hz
Power Adaptor
 AC-DC power supply
(Output: DC24V,2.7A)
Battery Operation
Max. up to 2 hours
(Rechargeable Li ion battery)
Interface
3 USB
Serial RS232
Ethernet RJ45
Barcode Scanner


Cartridge Specifications

Pack Size / On-Board Expiration
30 samples / 4 weeks
50 samples / 4 weeks
100 samples / 4 weeks
200 samples / 4 weeks
Storage Condition
10 - 30°C
Components
Electrodes
Cal 1, Cal 2
Reference Solution
Sampler & Tubing
Waste Bag
Dimension / Weight
138 x 139 x 80 mm / 0.8kg


Ordering Information

Product CodeProduct Description
WD1350i-Smart 30 VET Electrolyte Analyser
WD1351i-Smart 30 VET Cartridge (30 Tests)
WD1352i-Smart 30 VET Cartridge (50 Tests)
WD1353i-Smart 30 VET Cartridge (100 Tests)
WD1354i-Smart 30 VET Cartridge (150 Tests)
WD1355i-Smart 30 VET Cartridge (200 Tests)
WD1356i-Smart Electrolyte Quality Control (Multi Level 1/2/3)
WD1373i-Smart Electrolyte Quality Control (Ca++)
WD1367i-Smart 30 VET Cartridge E4, 30 Tests (Na, K, Cl, Ca++)
WD1368i-Smart 30 VET Cartridge E4, 50 Tests (Na, K, Cl, Ca++)
WD1369i-Smart 30 VET Cartridge E4, 100 Tests (Na, K, Cl, Ca++)
WD1371i-Smart 30 VET Cartridge E4, 150 Tests (Na, K, Cl, Ca++)
WD1372i-Smart 30 VET Cartridge E4, 200 Tests (Na, K, Cl, Ca++)
WD1374i-Smart 30 VET Cartridge E4, 6 Week Expiry, 30 Tests
WD1375i-Smart 30 VET Cartridge E4, 6 Week Expiry, 50 Tests
WD1376i-Smart 30 VET Cartridge E4, 6 Week Expiry, 100 Tests
WD1362Ai-Smart Clot Catcher (1 Pack of 10)
WD1357AC/DC (24V) Adaptor
WD1358Barcode Scanner
WD1359Printer Paper (1 Roll)
WD1360Analyser Base
WD1361i-Smart to PC, RS-232 Cable


If you would like more information please contact Woodley Equipment on +44 (0) 1204 669033 or email sales@woodleyequipment.com
